Example Analysis

To show how CogniCrypt_SAST works, we consider the following code example:

import java.security.GeneralSecurityException;
import javax.crypto.KeyGenerator;
import javax.crypto.SecretKey;
import javax.crypto.spec.SecretKeySpec;
import javax.crypto.Cipher;

public class Example {

    public static void main(String[] args) throws GeneralSecurityException {
        // "DES" is not allowed -> ConstraintError
        KeyGenerator generator = KeyGenerator.getInstance("DES"); // l1

        // Key size of 64 is not allowed -> ConstraintError
        generator.init(64);

        // KeyGenerator is not correctly initialized. Hence, the generated
        // key is not secure -> RequiredPredicateError
        SecretKey key = generator.generateKey(); // l2

        // "DES" is not allowed -> ConstraintError
        Cipher cipher = Cipher.getInstance("DES"); // l3

        // "key" is not securely generated -> RequiredPredicateError
        cipher.init(Cipher.ENCRYPT_MODE, key);

        // Cipher object is initialized but not used for encryption -> IncompleteOperationError
    }
}

Using the JCA rules, we can use the HeadlessJavaScanner to analyze the compiled version of this program:

java -jar HeadlessJavaScanner-x.y.z-jar-with-dependencies.jar \\
               --appPath ./Example.jar \\
               --rulesDir ./JCA-CrySL-rules.zip \\
               --framework Soot \\
               --reportFormat CMD \\
               --reportPath ./output/ \\
               --visualization

Observe that we use Soot as the underlying analysis framework, we print the report to the command line, and we enable the visualization. CogniCrypt_SAST runs the analysis and reports 3 ConstraintErrors, 2 RequiredPredicateErrors and 1 IncompleteOperationError, and their positions in the original programs. Additionally, since we use --visualization, it creates the following image visualization.png in the directory ./output/:

You can see that two ConstraintErrors on the object l1 (KeyGenerator) cause a RequiredPredicateError on the object l2 (SecretKey) which in turn causes a RequiredPredicateError on the object l3 (Cipher). Additionally, there is another ConstraintError and IncompleteOperationError on the Cipher object. Note that the variables and statements correspond to the intermediate representation Jimple. You can match the variables to the command line output that lists all analyzed objects.
